科勒（KOHLER）汽油发电机技术参数 |
|
|
|
技术参数/Technical parameters |
|
机组发电参数Generator set |
型号/Model |
KL-1200(KOHLER) |
|
额定功率/Reted power(kW) |
18.0 |
|
最大功率/Max power(kW) |
20.0 |
|
额定频率/Rated frequency(HZ) |
50 |
|
额定电压/Rated voltage(V) |
220 |
|
额定电流/Rated current(A) |
81 |
|
功率因数/Power factor(COSφ) |
1.0 |
|
相 数/Phase |
单相 |
|
发电机Generator |
发电机型号规格/Generator model |
20KW/50HZ |
|
极 数/Number of poles |
2 |
|
励磁方式/Excitation mode |
自激恒压(带AVR)/Self-excited constant voltage |
|
绝缘等级/Insulation grade |
F |
|
转 速(rpm)/Speed |
3000 |
|
发动机Engine |
发动机型号/Engine model |
CH980（KOHLER)(科勒美国原装进口) |
|
发动机形式/Engine type |
V形、双缸、风冷、四冲程、汽油发动机/V-twin cylinders,Air-cooled,4-stroke,gasoline engine |
|
缸径×冲程/Bore×Stroke(㎜) |
90×78.5 |
|
排量/Displacement(ml) |
999 |
|
标定功率(kW)/标定转数(rpm)/Rated power(kW)/Rated speed(rpm) |
28.3/3600 |
|
旋转方向/Rotation direction |
逆时针（面对输出端）/CCW（face to output side） |
|
压缩比/Compression ration |
09:01 |
|
润滑方式/Lubrucation method |
压力飞溅复合式/force-feed and splash lubrication |
|
起动方式/Starting method |
电起动/Electric starter |
|
润滑油容量/Lubrication capacity(L) |
2.75 |
|
燃油消耗率/Fuel consumption ratio(g/kW.h) |
285 |
|
润滑油型号/Lube.brand |
SAE10W－30 |
|
配置参数parameter parameters |
结构类型/Structure type |
开架式/Open-frame type |
|
噪音/Noise level/dB(A) |
72 |
|
燃油箱容积/Fuel tank capacity(L) |
30 |
|
连续运行时间(h)/Continuous working time |
6 |
|
蓄电池容量/Battery capacity(V-Ah) |
12-36 |
|
4寸轮子/4inch Wheel |
2个万向轮，2个定向轮(带刹车)/2-Wheel switch,2-Wheel battery capacity(With brakes) |
|
外形尺寸：长×宽×高/Packing size(mm) |
1020×670×700 |
|
净重/Net weight(Kg) |
185 |
|
毛重/Gross weight(Kg) |
205 |
|
20FT Qty |
32 |
|
40FT Qty |
64 |
|
|
|
|
|
|
通过认证
